High Efficiency Solar
AXN6M SERIES – Mono-Crystalline Solar Panels
72 Cell Mono
Finish: Black on Black & Standard White
Power Range: 330-365W
Size: 77.01″ x 39.06″ x 1.57″ (1956mm x 992mm x 40mm)
Weight: 47.2 lbs (21.4 kg)
Connector Type: MC4 or Tyco
System Voltage: 1000V
3% Positive Tolerance
Packing: 13 pcs/box; 26 pcs/pallet; 754 pcs/container (53′)
Manufactured in the U.S.A
60 Cell Mono
Finish: Black on Black & Standard White
Power Range: 265-305W
Size: 64.57″ x 39.06″ x 1.57″ (1640mm x 992mm x 40mm)
Weight: 39.8 lbs (18.1 kg)
Connector Type: MC4 or Tyco
System Voltage: 1000V
3% Positive Tolerance
Packing: 13 pcs/box; 26 pcs/pallet; 884 pcs/container (53′)
Manufactured in the U.S.A
AXN6P SERIES – Poly-Crystalline Solar Panels
72 Cell Poly
Finish: Black on Black & Standard White
Power Range: 285-335W
Size: 77.01″ x 39.06″ x 1.57″ (1956mm x 992mm x 40mm)
Weight: 47.2 lbs (21.4 kg)
Connector Type: MC4 or Tyco
System Voltage: 1000V
3% Positive Tolerance
Packing: 13 pcs/box; 26 pcs/pallet; 754 pcs/container (53′)
Manufactured in the U.S.A
60 Cell Poly
Finish: Black on Black & Standard White
Power Range: 240-290W
Size: 64.57″ x 39.06″ x 1.57″ (1640mm x 992mm x 40mm)
Weight: 39.8 lbs (18.1 kg)
Connector Type: MC4 or Tyco
System Voltage: 1000V
3% Positive Tolerance
Packing: 13 pcs/box; 26 pcs/pallet; 884 pcs/container (53′)
Manufactured in the U.S.A
Boutique Solar™
Auxin Solar manufactures high end solar products.
With our automation, we are able to design and manufacture custom solar products while maintaining the quality and cost of a fully scaled production process.
We work with our customers on R&D of custom solar products from concept to high volume production.
BIPV
BI-FACIAL
Frameless
Transparent
Integrated racking
Technology
Industry leading PTC
Bi-Facial integration
Linear power degradation
100% PID Resistance
Glass on Glass
One of our core values is continuous improvement.
Auxin Solar continues to invest in new process technology, latest equipment, latest raw materials and R&D on new circuit design applications for solar.
Production equipment is refreshed every 24 months on critical process steps.
New BOM is evaluated and integrated into end product every 12 months.
All new material goes through internal reliability testing as well as 3rd party testing.
All products are certified by UL and TUV Rhineland.
